High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly

Place of Origin : Guangdong, China

Brand Name : ODM

Model Number : SMT reflow oven 6/8/10/12 zones

Certification : CE ISO

Supply Ability : 10 Piece/Pieces per Week

Packaging Details : 1.wooden case 2.As your order

MOQ : 1pcs

Price : 7042~14082$

Payment Terms : T/T, Western Union, Paypal, Credit card

Delivery Time : 5-8 days

Product name : SMT reflow oven 6/8/10/12 zones

Voltage : 220V

Current : 20A

Rated Capacity : 4800W

Rated Duty Cycle : 60%

Dimensions : 640*630*900mm

Usage : Welding Machine

Model number : reflow oven 6/8/10/12 zones

package : wooden case

Condition : new

Type : SMD reflow soldering machine, Other

Brand : ODM

Delivery : ups,dhl,fedex,as your order

Weight : 45kg

After-sales Service Provided : Engineers available to service machinery overseas

Port : shenzhen

Contact Now

High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly Name: SMT reflow oven

The domestic reflow soldering machine is a crucial piece of equipment in the electronics manufacturing industry, primarily used for soldering surface mount devices (SMDs) onto printed circuit boards (PCBs). This machine ensures reliable electrical connections and is essential for producing high-quality electronic assemblies.
Functionality:
1. Heating Process: The reflow soldering machine uses a controlled heating process to melt solder paste applied to the PCB. The heating is typically done in multiple zones, allowing for precise temperature control to avoid damaging sensitive components.
2. Solder Paste Application: Prior to reflow, solder paste is applied to the PCB pads. The machine can accommodate various types of solder pastes, ensuring compatibility with different components and applications.
3. Conveyor System: The machine features a conveyor system that transports PCBs through different heating zones. This continuous movement allows for efficient processing of multiple boards in a single run.
4. Cooling Phase: After the soldering process, the PCBs enter a cooling zone where they are rapidly cooled to solidify the solder joints. This step is critical for ensuring strong and reliable connections.
5. Quality Control: Many reflow soldering machines include integrated inspection systems to check for defects such as insufficient solder or misaligned components, ensuring that only quality products proceed to the next manufacturing stage.
Usage Instructions:
1. Setup: Position the reflow soldering machine in a clean and controlled environment. Ensure all necessary connections and materials are ready.
2. Load PCBs: Place the PCBs onto the conveyor system, ensuring they are properly aligned and secured.
3. Configure Settings: Use the control panel to input parameters such as temperature profiles, conveyor speed, and time settings based on the solder paste specifications.
4. Start the Reflow Process: Activate the machine and monitor the process to ensure that the heating and cooling phases occur as planned.
5. Regular Maintenance: Conduct routine checks and maintenance to ensure the machine operates efficiently and reliably.
RF-8820PC-LF WZ-8810PC/LS-LF WZ-8830PC/LS-LF
Dimension 5000×1200×1550mm 4600×1000×1550mm 4600×1500×1550mm
Weight 1800kg 1200kg 1600kg
Number of heating zone Top 8/Bottom 8
Length of heating zone 3160mm 2800mm 2800mm
Cooling quantity Up 2/Bottom 2 Up 1/Bottom 1 Up 1/Bottom 1
Air discharge requirement 10m³/min×2
Power requirements 3 phase 380V 50/60Hz
Starting power 36KW 32KW 48KW
Operating power 7KW 6.5KW 8KW
Heating time Approx: 20min
Temperature control range Room temp-320°C
Temperature control Mode PID closed-loop control with SSR drive (computer + PLC)
Temperature control precision ±1°C
Temperature deviation On PCB ± 2°C
Abnormal alarm Ultra high temperature or low temperature alarm
Maximum width of PCB 50-500mm 50-450mm 50-600/700/800mm
Guide rail width range 50-400mm 50-370mm 50-500/600/700mm
PCB element height Top 30mm Bottom 25mm
Transportation direction L-R (Option: R-L)
Transportation speed 0-1800mm/min
Transportation height 900±20mm
Transport guide rail fixation Front end fixed (Option: Back end fixed)
Cooling mode Force wind cooling
PCB transport mode Chain +Ribbon Chain (Chain optional) Chain (Chain optional)
Application Areas:
Domestic reflow soldering machines are widely used in:
1. Consumer Electronics: For assembling devices like smartphones, tablets, and computers.
2. Automotive Electronics: In the production of electronic control units and sensors.
3. Medical Devices: For soldering components in critical medical equipment.
The domestic reflow soldering machine is essential for ensuring high-quality solder joints and reliable electronic assemblies in various applications.


The main brand is Fuji YAMAHA Samsung SONY heavy machine
1. SMT lubricating oil
2. SMT parts
3. Nozzle and feeder
4. SMT belt and other parts in the machine

High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly

High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB AssemblyHigh Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB AssemblyHigh Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly

High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly

High Efficiency Benchtop Reflow Oven Dual Zone Temperature Control Reflow Soldering for SMT PCB Assembly
